Portable Ambient Air Quality Monitoring System
Agasthya 2013 Series
BI 9100
The Agasthya 2013 Series Portable Ambient Air Quality Monitoring Analyzer – BI 9100 is a compact and modular air quality monitoring system designed to deliver accurate real-time and intermittent measurement of ambient air quality parameters across diverse environments.
The BI 9100 AQMS measures key gaseous pollutants including Ozone (O3), Nitrogen Dioxide (NO2), Nitric Oxide (NO), Carbon Monoxide (CO), Carbon Dioxide (CO2), Sulphur Dioxide (SO2), Hydrogen Sulphide (H2S) and other toxic gases using proven Electrochemical and Infrared (IR) sensor technologies.
Designed for portability and flexible deployment, the BI 9100 enables cost-effective air quality monitoring with reliable long-term performance. Measurement data is stored internally and can be accessed remotely in real time via RS-485 communication supporting MODBUS protocol, meeting global requirements for micro-environment air quality assessment.
- Portable and compact ambient air quality monitoring analyzer
- Measurement of up to 6 parameters under one system
- Electrochemical and Infrared (IR) sensor technologies
- 5.7-inch touch screen display
- 32-bit powerful ARM processor
- Real-time data acquisition
- Active sampling via brushless pumps
- Excellent linearity and sensitivity
- Negligible zero and span calibration slope drift
- Built-in zero air scrubber
- Zero and Span gas calibration at site
- Multi-point factory calibration
- Remote site operation capability
- MODBUS communication support
- PC software included
- Low capital cost for affordable air quality profiling and assessments
Analyzer Specification
- Gas Measurement Technology
- Electrochemical
- Gas Measurement Range
-
- Oxygen (O₂) : 0–25 %
- Carbon Monoxide (CO) : 0–50 ppm
- Nitric Oxide (NO) : 0–5000 ppb
- Nitrogen Dioxide (NO₂) : 0–5000 ppb
- Sulphur Dioxide (SO₂) : 0–5000 ppb
- Hydrogen Sulphide (H₂S) : 0–10000 ppb
- Ozone (O₃) : 0–1000 ppb
- Ammonia (NH₃) : 0–25 ppm
- Chlorine (Cl₂) : 0–10000 ppb
- Carbon Dioxide (CO₂) : 0–2000 ppm
- Methane (CH₄) : 0–2000 ppm
- HCl : 0–10 ppm
- Particulate Matter
-
- PM10 : 0.001–20 mg/m³
- PM2.5 : 0.001–20 mg/m³
- TSP : Optical sensor based
- Ambient Conditions
-
- Ambient Temperature : –40°C to +60°C
- Relative Humidity : 0–100 % RH
- Barometric Pressure : 800–1100 hPa
- TVOC : Up to 10,000 ppm
CEMS Specification
- Analog Output
- 4–20 mA for each gas
- Communication Interface
- RS-232, RS-485
- Protocol
- MODBUS
- Power Supply
- 110 / 230 VAC, 50 Hz
- Operating Temperature
- –20°C to +50°C
- Operating Relative Humidity
- 15–85 % RH
- Dimensions
- 1500 (H) × 600 (W) × 800 (D) mm
- Weight
- 200–300 kg (configuration dependent)
- Park and forest air quality monitoring
- Indoor air quality monitoring
- Industrial perimeter air quality monitoring
- Local community exposure monitoring (residential, schools, hospitals)
- Construction site air quality monitoring
- Urban ambient air quality monitoring
- Near-road and traffic pollution monitoring
- Ecological mobility management
- Long-term air quality trend analysis
- Environmental impact assessments
- Low-cost air quality networks supporting reference AAQM stations
- Technical Brochure
- Manual
- Application Questionnaire
